Diode Small Signal Switching BAV103 BAV103,115

Basic Info.

Model NO.	BAV103
Package	LL-34
Quality	Genuine New Original
D/C	17+
MFG.	NEXPERIA
Transport Package	Box
Origin	China
HS Code	8542390000
Production Capacity	1000000PCS

Product Description

Description

BAV103: Diode Switching 250V 0.25A 2-Pin Mini-MELF T/R

Package: SC-70-6

Mfr. Part#: BAV103

Mfr.: NEXPERIADatasheet: (e-mail or chat us for PDF file)

ROHS Status:

Quality: 100% Original

Warranty: 180 days

Product Status	Active
Technology	Standard
Voltage - DC Reverse (Vr) (Max)	200 V
Current - Average Rectified (Io)	200mA
Voltage - Forward (Vf) (Max) @ If	1.25 V @ 200 mA
Speed	Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr)	50 ns
Current - Reverse Leakage @ Vr	100 nA @ 200 V
Capacitance @ Vr, F	5pF @ 0V, 1MHz
Mounting Type	Surface Mount
Package / Case	DO-213AC, MINI-MELF, SOD-80
Supplier Device Package	SOD-80
Operating Temperature - Junction	-65°C ~ 200°C
Base Product Number	BAV10

Single general-purpose switching diodes, fabricated in planar technology, and encapsulated in small hermetically sealed glass SOD80C Surface-Mounted Device (SMD) packages.

Key Features

• High switching speed: t_rr ≤ 50 ns
• Low capacitance: C_d ≤ 5 pF
• Low leakage current
• Small hermetically sealed glass SMD package
